Description

Every concrete pour is a race, and the finish line is the initial set. Between the moment the mix hits the deck and the moment it stops being workable, a slab crew has to strike it to level, lift the slurry, close the surface and hold the elevation — across hundreds or thousands of square metres, with the concrete stiffening under them by the minute. The BMR Concrete Leveling Robot from BrightMaster Robotics runs that race on wheels and lasers, replacing traditional manual screeding on large-scale flooring projects.

Guided by a high-precision laser reference — Topcon or MOBA systems depending on the variant — the robot automatically adjusts screed height, vibration frequency and travel speed in real time, performing slurry lifting, surface finishing and elevation control before the concrete's initial set. The target is millimetre-level flatness held across a full pour, which manual methods cannot reliably sustain.

The family spans two working widths and four models. The 1.5-metre 15SY and 15MY are 175-kilogram machines levelling 30 to 150 millimetres at 160 square metres per hour or more; the 2.5-metre 25SY and 25MY are 350-kilogram machines levelling 30 to 250 millimetres at 300 square metres per hour or more. All four are remote-controlled and battery-electric, quiet enough for night pours in occupied districts.

Flatness is money: warehouse racking, forklift speeds, machine foundations, crack behaviour and floor-covering budgets all trace back to how the slab was levelled in its first workable hour. Rather than following screed rails and eyesight, the machine corrects its screed head continuously against a laser plane projected across the whole slab, and BMR's independently developed dual-degree-of-freedom adaptive system with intelligent motion-control algorithms keeps that head true even as the chassis rides the uneven, reinforcement-strewn surface of a live pour. The result is repeatable, industrial-grade flatness with reduced surface cracking and a dense, uniform finish.

The Concrete Leveling Robot is a quote-only item, available internationally. Units are sourced new through established distribution channels and carry the full manufacturer warranty. Robotix Market ships worldwide, and after-sales support is coordinated with BrightMaster Robotics' service network. On-site installation and commissioning are not included. Delivery and customs clearance are arranged for the destination market.

Official Product Videos

Features

Laser-Guided Screed Reference A high-precision laser reference — Topcon or MOBA depending on the variant — replaces screed rails and eyesight, giving the machine a plane projected across the whole slab to correct against.
Real-Time Height, Vibration and Speed Control Screed height, vibration frequency and travel speed are adjusted automatically in real time against the laser reference rather than set once and held.
Dual-Degree-of-Freedom Adaptive System BMR's independently developed two-degree-of-freedom adaptive system with intelligent motion-control algorithms holds the screed head true even as the chassis rides the uneven, reinforcement-strewn surface of a live pour.
Two Working Widths, Four Models The 1.5 m 15SY and 15MY weigh 175 kg and level 30 to 150 mm at 160 m²/h or more; the 2.5 m 25SY and 25MY weigh 350 kg and level 30 to 250 mm at 300 m²/h or more.
Full Cycle Before Initial Set Slurry lifting, surface finishing and elevation control are all completed before the concrete's initial set, to millimetre-level flatness with reduced surface cracking and a dense, uniform finish.
Battery-Electric and Remote-Controlled All four models are remote-controlled and battery-electric — no engine exhaust on enclosed decks and quiet enough for night pours in occupied districts.

Specs

Brand	BrightMaster Robotics
Model	15SY, 15MY (1.5 m) and 25SY, 25MY (2.5 m)
Product Type	Laser-guided robotic concrete levelling and screeding robot
Working Width	1.5 m (15SY / 15MY) or 2.5 m (25SY / 25MY)
Levelling Thickness	30 to 150 mm (1.5 m models); 30 to 250 mm (2.5 m models)
Working Efficiency	160 m²/h or more (1.5 m models); 300 m²/h or more (2.5 m models)
Machine Weight	175 kg (1.5 m models); 350 kg (2.5 m models)
Laser Reference	Topcon or MOBA system, by variant
Control	Remote controlled
Power	Battery-electric

Industries

Construction
Industrial
Infrastructure

Frequently Asked Questions

What is the BMR Concrete Leveling Robot used for?

It is a laser-guided robotic screed that replaces traditional manual screeding on large-scale flooring projects. It performs slurry lifting, surface finishing and elevation control before the concrete's initial set, holding millimetre-level flatness across a full pour.

Which model should I choose, the 1.5 m or the 2.5 m?

The 1.5-metre 15SY and 15MY weigh 175 kg and level 30 to 150 mm at 160 m²/h or more. The 2.5-metre 25SY and 25MY weigh 350 kg and level 30 to 250 mm at 300 m²/h or more. Wider is faster on open pours; the narrower machines are easier to handle where access is restricted.

How does the robot achieve its flatness?

It follows a high-precision laser plane projected across the slab — Topcon or MOBA systems by variant — adjusting screed height, vibration frequency and travel speed in real time. An independently developed dual-degree-of-freedom adaptive system with intelligent motion-control algorithms keeps the head true while the chassis rides the uneven, reinforcement-strewn surface of a live pour.

How much does the BMR Concrete Leveling Robot cost?

The BMR Concrete Leveling Robot is priced at $44,551.82 in your market. For volume or project orders, contact us for a business quote.

How is the robot supplied and supported?

Units are sourced new through established distribution channels and carry the full manufacturer warranty. Robotix Market ships worldwide and arranges delivery and customs clearance, with after-sales support coordinated through BrightMaster Robotics' service network. On-site installation and commissioning are not included.
