Description

The Dobot Hexplorer is a hexapod bionic robot designed for stable, capable operation across irregular and complex terrain. Its six-legged layout uses a biologically inspired gait strategy that keeps multiple legs grounded simultaneously, providing inherent static stability on surfaces where bipedal or quadrupedal robots face greater balancing challenges. With 18 degrees of freedom and a maximum walking speed of 1.8 m/s, the Hexplorer handles obstacle heights up to 20 cm and slopes up to 40 degrees, making it well-suited for research fieldwork, inspection tasks, and outdoor or industrial environment traversal. The platform weighs approximately 20 kg and can be folded to 73.4 cm × 47 cm × 24.5 cm for transport, while its rated payload of 10 kg and maximum payload of 15 kg provide meaningful capacity for sensors and mounted equipment.

Hexplorer's compute stack is built around an x86_64 Intel Core i7/i5 processor with approximately 40 TOPS of GPU performance, and the robot integrates a Livox Mid-360 LiDAR alongside an Intel RealSense D435 RGB-D camera for terrain mapping, obstacle awareness, and spatial sensing. ROS 2 high-level and low-level SDKs with Python and C++ support, MuJoCo simulation compatibility, IMU data, and motor and joint feedback round out a development-oriented software environment. The modular platform accepts additional sensors, manipulators, AI modules, depth cameras, collaborative arms, and edge computing devices, giving teams a flexible base for research, inspection, and field task development.

Official Product Videos

Features

Six-Legged Bionic Stability Hexapod gait keeps multiple legs grounded simultaneously, providing inherent static stability on irregular, slippery, or constrained terrain.
18 DOF with 1.8 m/s Speed 18 degrees of freedom and a top speed of 1.8 m/s, with 20 cm obstacle height clearance and 40° slope capability.
10–15 kg Payload Capacity Rated at 10 kg with a 15 kg maximum, accommodating substantial sensor, tool, or equipment payloads for field and inspection deployments.
Livox Mid-360 LiDAR and RealSense D435 Integrated LiDAR and RGB-D camera provide terrain mapping, obstacle detection, depth estimation, and spatial sensing for navigation and research tasks.
x86_64 Compute with ROS 2 Support Intel Core i7/i5 with ~40 TOPS GPU runs ROS 2 SDKs in Python and C++, with MuJoCo simulation, IMU, and motor/joint feedback for full development workflows.
Modular Expansion Platform Accepts sensors, manipulators, AI modules, LiDAR, depth cameras, voice modules, and collaborative arms for mission-specific customization.

Specs

Brand	Dobot
Model	Hexplorer
Degrees of Freedom	18 DOF
Maximum Walking Speed	1.8 m/s
Maximum Slope	40°
Net Weight	~20 kg
Dimensions (standing)	86.3 cm × 47 cm × 48 cm
Rated Payload	10 kg
Maximum Payload	15 kg
Battery	504 Wh, ~2.5 hours
LiDAR	Livox Mid-360
Depth Camera	Intel RealSense D435 RGB-D
Compute	Intel Core i7/i5, x86_64, ~40 TOPS GPU
Software	ROS 2 (Python/C++), MuJoCo simulation

Industries

Research
Inspection
Education

Frequently Asked Questions

What is the price of the Dobot Hexplorer Six-Legged Bionic Robot?

The Dobot Hexplorer Six-Legged Bionic Robot is priced at $18,995 in your market. For volume or project orders, contact us for a business quote.

What is the Dobot Hexplorer and what is it used for?

The Hexplorer is a six-legged bionic robot designed for stable traversal of complex and irregular terrain. It serves research, inspection, and field deployment scenarios where legged mobility, meaningful payload capacity, and programmable development interfaces are required.

What are the Hexplorer's key performance capabilities?

The Hexplorer moves at up to 1.8 m/s, handles 20 cm obstacle heights and 40° slopes, carries 10–15 kg payload, and runs for approximately 2.5 hours on its 504 Wh battery. Its hexapod gait maintains static stability in conditions where bipeds and quadrupeds can struggle.

Which industries and use cases does the Hexplorer serve?

The Hexplorer is suited to robotics research, field inspection, university education, and development teams building legged robot applications. Its modular expansion support for LiDAR, cameras, manipulators, and AI modules makes it adaptable to many mission profiles.

What are the shipping and warranty terms?

Robotix Market ships the Dobot Hexplorer worldwide. The product is covered by the manufacturer's warranty as specified by Dobot; no third-party or on-site service warranty is included.

How do I purchase the Hexplorer or request a quote?

Contact Robotix Market through the website to request pricing, discuss configuration and accessory options, or arrange international shipping. Our team can assist research and industrial customers throughout the procurement process.

Dobot

Dobot Hexplorer Six-Legged Bionic Robot

Regular price: $18,995.00
Sale price

Unit price

The Dobot Hexplorer is an 18-DOF hexapod robot with a 1.8 m/s top speed, 10–15 kg payload, Livox Mid-360 LiDAR, Intel RealSense D435, and x86_64 compute with full ROS 2 support, designed as a modular, field-capable legged platform for research, inspection, and terrain-adaptive deployment.

In Stock

OriginChina

WarrantyManufacturer warranty

SKUDobot-Hexplorer
