SCHUNK PGN-Plus-P

The PGN-Plus-P is a pneumatic gripper from the Plug & Work portfolio of SCHUNK. With a maximum stroke of 20 mm, a gripping force of 870 N and a payload of 4,35 kg, the PGN-plus-P gripper offers a powerful and precise pneumatic gripping solution.
Weight

1,8 kg

Payload

4,35 kg

Portfolio
Reset
Technical questions

1.980,00 € excl. VAT

From 200,00 € per month as a lease or in instalments.

Leasing & Purchasing Guide
  • Specifications
  • Overview
  • Description
  • Downloads
  • FAQ
  • Similar products

Overview

Robust multi-tooth sliding guide

High torque capacity

Lubricant pockets in the multi-tooth guide profile

Featured on Unchained TV

video-image
Pick & PlaceMetalMechanical engineering

Flexible production through automation with OMRON Cobots

Specifications

Overview
Payload4,35 kg
Weight1,8 kg
Dimensions113 x 97 x 124 mm
Number of fingers2
Operating modePneumatic

Performance
Min. operating temperature 5 °C
Max. operating temperature90 °C
Nominal operating pressure6 bar
Max. operating pressure8 bar
Stroke20 mm
Max. gripping force870 N

Interface
Supply voltage24 V
CommunicationIO
Mounting interfaceISO 9409-1-50-4-M6
Compressed air supplyISO 8573‐1: 7:4:4

Features
IP ratingIP 40/46

Description

The SCHUNK PGN-plus-P is a pneumatic gripper for flexible workpiece handling. With a max. gripping force of 870N, workpieces weighing up to 4,35kg are recommended for handling. The stroke per jaw is 10mm, providing a total stroke of 20mm. Weighing 1,8kg, the pneumatic gripper without finger tips is ideal for use with robots from the brands Universal Robots, Omron/TM and Doosan. The weight may vary slightly depending on the variant.

The SCHUNK PGN-plus-P is part of the Plug & Work portfolio, which includes electrically and pneumatically controlled grippers, quick-change modules and force/torque sensors. The SCHUNK End-of-Arm modular system offers a wide range of combinations for handling the product of your choice.

Technical data

  • Stroke: 16 - 20 mm
  • Gripping force: 550 - 870 N
  • Weight: 1,38 - 1,8 kg
  •  Payload: 2,75 - 4,35 kg
