Robotis - EPX430-BR101 Set

Features The EPX430-BR101 is an optional horn for the DYNAMIXEL XM/XH/XD430 series. The horn connected to the output shaft distributes radial load and minimizes wear. Package Contents Product Quantity Description EPX430-BR101 1 Horn for output shaft Wrench Bolt (WB M2.5x17) 3 Bolts for upper part assembly Wrench Bolt (WB M2.5x5) 3 Bolts for lower part assembly Wrench Bolt (WB M2.5x8) 2 Bolts for horn-shaft assembly (XM/XH430 models) Wrench Bolt (WB M3x8) 2 Bolts for horn-shaft assembly (XD430 models) Thrust washer 1 Washer for preventing rotational friction How to Assemble Please be sure to check the assembly instruction below before use. Link ○ Drawing ○ Compatibility Guide
