| Arm | ||
|---|---|---|
| Reach | 1.350 mm | |
| Payload | 32 kg | |
| Dead weight | 61 kg | |
| Performance | ||
|---|---|---|
| Max. linear TCP speed | 6 m/s | |
| Repeatability | 0,03 mm | |
| Min. operating temperature | 5 °C | |
| Max. operating temperature | 45 °C | |
| Joint movement (range: ° / max. speed: ° /s) | ||
|---|---|---|
| J1 | -360 to 360 | ±149 |
| J2 | -180 to 180 | ±149 |
| J3 | -243 to 74 | ±230 |
| J4 | -360 to 360 | ±300 |
| J5 | -270 to 270 | ±300 |
| J6 | -400 to 400 | ±300 |
| J7 | - | - |
| Other features | ||
|---|---|---|
| IP rating | IP67 | |
| Noise level | 65 dB | |
| Mounting orientation | Any orientation | |
| Control Box | ||
|---|---|---|
| Dimension | 449 x 338 x 89 mm | |
| Weight | 12 kg | |
| Communication | PROFINET Controller, PROFINET Device, PROFIsafe Controller, PROFIsafe Device, CC-Link IE MASTER, CC- Link IE Device, CC – Link Safety Master**, CC – Link Safety Device**, EtherCAT device, EtherCAT Master**, EtherCAT FSoE device, EtherCAT FSoE Master**, Ethernet/IP Adapter, Ethernet/IP Scanner, CIP Safety Adapter, CIP Safety Scanner** ** Available soon | |
| IP rating | IP20 | |
| Teach Panel | ||
|---|---|---|
| Weight | 1,2 kg | |
| Cable length | 3 m | |
| IP rating | IP67 | |
The PoWa 30 from ABB is a six-axis collaborative robot from the CRB-1920 series, designed for industrial applications requiring a higher payload. Its reach is 1,35 m at the wrist and 1,52 m at the flange. Its rated payload is 30 kg, and it can handle payloads of up to 32 kg in the wrist-down configuration.
At rated payload, the PoWa 30 reaches a maximum TCP speed of 3,9 m/s. With a payload of 1 kg, speeds of up to 6,0 m/s are possible. Pose repeatability is 0,03 mm, and path repeatability is 0,1 mm. The robot weighs 61 kg and has an IP67 rating.
The Wizard Easy Programming App on the FlexPendant can be used for programming and commissioning. It lets you create motion sequences using a block-based interface. Programmable buttons are also available on the robot arm. Integration with ABB solutions such as RobotStudio and AppStudio supports further planning, configuration and programming tasks.
The PoWa 30 is also designed for flexible applications when it comes to tool connections. Grippers and vision systems can be integrated simultaneously, making it possible to carry out a range of tasks with relatively little installation effort. Typical applications include material handling, machine tending, palletizing, assembly and screwdriving.
